Pipes

Pipes

In grade IS 3589 Fe 330, Fe 410, Fe 450, IS 4270 and ASTM A53 Gr. A & B

Diameter (Inch)	Thickness (mm)
8 5/8	4.8	5.2	5.6	6.0	6.4	7.1	7.9	9.5	10
10 3/4	4.8	5.2	5.6	6.0	6.4	7.1	7.9	9.5	10
12 3/4	5.0	5.2	5.6	6.0	6.4	7.1	7.9	9.5	10
14	5.0	5.2	5.6	6.0	6.4	7.1	7.9	9.5	10
16		5.2	5.6	6.0	6.4	7.1	7.9	9.5	10
18		5.2	5.6	6.0	6.4	7.1	7.9	9.5	10

Pipes can be supplied with rust preventive coatings like varnish, red oxide, enamel, liquid epoxy coating, 3LPE coating etc. SW Pipes In grades IS 3589 Fe 330, Fe 410, Fe 450 and IS 5504

Outer Diameter
OD (Inch)	OD (mm)
20	508
24	609.6
28	711.2
32	812.8
36	914.4
40	1016
44	1117.6
48	1219.2
52	1320.8
56	1422.4
60	1524.0
64	1625.6

Pipes can be supplied with rust preventive coatings like varnish, red oxide, enamel, liquid epoxy coating, 3LPE coating etc. Other ODs between 20" and 64" can also be produced.
